3.96 mm Three-Row Machined Pin Header for CNC Machine Tools & Industrial Controllers
Product Description
| Item |
Specification |
| Pitch |
3.96 mm (0.156 inch), center‑to‑center |
| Rows |
3‑Row |
| Mounting Type |
Through‑hole (DIP) soldering; Straight / Right‑angle optional |
| Available Positions |
Custom pin count per row; 3‑40 positions total, OEM acceptable |
| Pin Construction |
Precision CNC machined solid pin (not stamped) |
| Pin Cross‑section |
Square machined pin (custom dimension available) |
| Rated Current |
7 A max per contactHRB Connec... |
| Rated Voltage |
300 V AC |
| Contact Resistance |
≤10 mΩ (initial) |
| Insulation Resistance |
≥1000 MΩ DC 500 V |
| Dielectric Withstanding Voltage |
1500 V AC, 1 minute |
| Operating Temperature Range |
-40 °C ~ +120 °CHRB Connec... |
| Mating Cycles |
Minimum 500 cycles |
| Compliance |
RoHS 2.0, REACH |
| Compatible Mating Part |
Matching 3.96 mm three‑row female machined socket |
Our 3.96 mm three‑row machined pin header is a high‑reliability board‑to‑board / board‑to‑cable interconnect purpose‑built for CNC machine tools, PLC systems and heavy‑duty industrial controllers. Unlike conventional stamped pin headers, it adopts full CNC machined solid contacts to deliver superior mechanical stability, low contact resistance and consistent performance under vibration, temperature cycling and repeated mating cycles. Three‑row layout maximizes I/O density within limited PCB footprint, handling mixed signal and low‑power circuits for factory automation equipment. Fully RoHS & REACH compliant, supports through‑hole DIP soldering for industrial‑grade assembly conditions.
Material Details
| Component |
Material & Finishing |
| Housing / Insulator |
High‑grade PA6T / PBT thermoplastic, UL94 V‑0 flame retardant; Black standard color Wayconn El... |
| Contact Base Material |
High‑strength brass/copper alloy, precision CNC turning |
| Plating Base Layer |
Nickel under‑plating (anti‑corrosion barrier) |
| Contact Surface Finish |
Standard: Tin over Nickel; Option: Selective/full Gold plating for high‑vibration / long‑life applications |
| Retention Structure |
Injection‑molded interlock, pins firmly locked inside housing to avoid pin‑loosening under shock & vibration |
Application Industries & Typical End‑Equipment
- CNC Machine Tools: CNC controller mainboard, servo driver interface, machine I/O expansion board, numerical control system signal interconnection
- Industrial Automation & Controllers: PLC modules, motion control cards, industrial relay control units, field‑bus peripheral boards
- Factory Automation Equipment: Automated production line control boxes, robot auxiliary control boards
- Power & Energy Industrial Devices: Industrial power monitoring units, inverter internal signal connections
- Test & Measurement Instruments: Industrial test equipment, embedded industrial control hardware
Suitable for scenarios requiring high mechanical reliability, anti‑vibration, long service life and frequent field maintenance.
Customization Options
- Orientation: Straight vertical / 90° right‑angle
- Pin length & PCB through‑hole tail length customization
- Plating: Tin‑nickel standard; full gold / selective gold upon request
- Total pin positions: custom pin combinations for three‑row layout
- Special stand‑off / elevated housing height
- Custom marking, packaging (tray/tube / bulk bag)
Why Choose Us
- Professional industrial connector manufacturer, focusing on machined‑pin interconnect solutions for automation equipment
- Free engineering samples available for customer validation
- In‑house mold & CNC machining capacity, fast lead‑time for custom modifications
- Strict incoming‑to‑final QC testing: dimensional inspection, contact resistance, high‑voltage withstand, vibration test
- OEM & ODM support for machine tool and industrial controller manufacturers worldwide.
FAQ
Q: What's your MOQ?
A:Our MOQ usually comes to 1000 pcs, but we accept small order quantities for testing.
Q: Can I visit your factory?
A: Welcome to visit our factory, and we will show you our professional production process, and hoping we can have long-term cooperation with you.
Q: What's your sample time? What's your delivery time?
A:7 days for samples, and 15-20 days for mass production. It depends on the quantity.
Q: How do I inspect my goods?
A: You can inspect by visiting the factory, or ask a third party to inspect, or by picture inspection.
Q: How much does it cost to ship to my country?
A: The freight will be given by the freight company based on your Gross Weight and CBM.
Q: How do I know if you ship out my order?
A: The tracking number(DHL, UPS, FedEx, TNT, EMS, etc.), Air Waybill, or B/L by Sea will be sent to you as soon as your goods are shipped out. We also follow up on the delivery and keep you informed. The helpful after-service is provided. We support what you sell.
Q: Can I make personalized/customized products?
A: Sure, just send us your drawing or sample.
